Matrix X-Sabre 3 Streamer

DAC Chip ES9038Pro
CPU NXP i.MX 6Quad 4x Cortex-A9 @ 1.2GHz
Clock Crystek CCHD-950
Ulazi 1x Coaxial
1x Optical Toslink
1x I2S LVDS via HDMI
1x USB-B
1x RJ45
WiFi (DLNA, UPnP, AirPlay)
1x Trigger 12V
Izlazi 1x Single-ended stereo RCA
1x Balanced stereo XLR
Supported samplinf rates Optical / Coaxial : PCM up to 24bit 192 kHz, DSD DoP up to DSD64
I2S LVDS : PCM up to 32bit 768 kHz, Native DSD up to DSD512, DSD DoP up to DSD256
USB : PCM up to 32bit 768 kHz, Native DSD up to DSD512, DSD DoP up to DSD256, MQA up to 24bit 384 kHz or MQA Studio Stream
SNR XLR : > -134 dB
RCA : > -128 dB
THD+N XLR : < 0.00010% @ 1 kHz, < 0.00025% @ 20 Hz-20 kHz RCA : < 0.00015% @ 1 kHz, < 0.00025% @ 20 Hz-20 kHz Frekvencijski odziv XLR : 20 Hz-20 kHz ±0.05-3 dB @ 86 kHz RCA : 20 Hz-20 kHz ±0.05-3 dB @ 86 kHz Crosstalk XLR : > -151 dB
RCA : > -138 dB
Izlaz level XLR : 4.8Vrms @ 0 dB
RCA : 2.4Vrms @ 0 dB
Network LAN : 10/100/1000Mbps
WLAN : 2.4/5GHz
MA Player Lite Roon Ready : PCM up to 32bit 768 kHz, MQA up to 24bit 384 kHz or MQA Studio Stream, Native DSD up to DSD512
AirPlay
DLNA / UPnP
Tidal Connect
Spotify Connect
Supply voltage 100-240V 50/60 Hz (switchable input voltage)
Consumpation Max : < 33W
En veille : < 4W
Dimenzije 310 x 218 x 43mm
Težina 3.4 kg

Tehnički podaci su preuzeti sa zvaničnih sajtova proizvođača i mogu biti izmenjeni bez prethodne najave ili obaveštenja.
