Matrix Element I2

Inputs 1x Coaxial
1x Optical
1x I2S LVDS via HDMI
1x USB-B
1x RJ45
Outputs 1x Stereo RCA
1x Stereo XLR
1x Balanced Jack 4.4mm headphone output
1x Single-ended Jack 6.35mm headphone output
CPU NXP i.MX 6Quad Cortex-A9
DAC Chip ES9038Q2M
Clock Crystek CCHD-950
Supported sampling rates Coaxial / Optical : PCM up to 24bit 192kHz, DSD DoP64
I2S LVDS : PCM up to 32bit 768kHz, Native DSD up to DSD512, DSD DoP up to DSD256
USB-B : PCM up to 32bit 768kHz, Native DSD up to DSD512, DSD DoP up to DSD256, MQA up to 24bit 384kHz
SNR RCA Output : > -118dB A-Weighting
XLR Output : > -120dB A-Weighting
Balanced Jack 4.4mm headphone output : > -116dB A-Weighting
Single-ended Jack 6.35mm headphone output : > -114dB A-Weighting
THD+N RCA Output : < 0.00035% @ 1kHz, < 0.00050% @ 20Hz-20kHz
XLR Output : < 0.00025% @ 1kHz, < 0.00035% @ 20Hz-20kHz
Balanced Jack 4.4mm headphone output : < 0.0006% @ 20Hz-20kHz 4Vrms
Single-ended Jack 6.35mm headphone output : < 0.0008% @ 20Hz-20kHz 2Vrms
Frequency response RCA Output : 20Hz-20kHz ±0.1 -3dB @ 80kHz
XLR Output : 20Hz-20kHz ±0.1 -3dB @ 80kH6
Balanced Jack 4.4mm headphone output : 20Hz-20kHZ ±0.1 -3dB @ 65kHz
Single-ended Jack 6.35mm headphone output : 20Hz-20kHz ±0.1 -3dB @ 65kHz
Output level RCA Output : 2Vrms @ 0dB
XLR Output : 4Vrms @ 0dB
Headphone output impedance Balanced Jack 4.4mm headphone output : < 22Ω
Single-ended Jack 6.35mm headphone output : < 11Ω
Headphone output power Balanced Jack 4.4mm headphone output : 1500mW @ 33Ω, 950mW @ 300Ω, 500mW @ 600Ω, 1% THD
Single-ended Jack 6.35mm headphone output : 1200mW @ 33Ω, 260mW @ 300Ω, 130mW @ 600Ω, 1% THD
Headphone output gain +16.5dB
Network LAN : 10/100/1000Mbps
WLAN : 2.4GHz / 5GHz
Control app MA Remote
Supported file formats MP3, WMA, WAV, AIF, AIFC, AIFF, AAC, FLAC, OGG, APE, ALAC, M4A, DSF, DFF, CUE
Supported transmission protocols AirPlay 2
DLNA/UPnP
TIDAL Connect
Spotify Connect
vTuner
Supply voltage 100-240VAC 50/60Hz
Consumption En veille : < 5W
Max : < 30W
Dimensions 240 x 259 x 58mm
Weight 2.6kg

Tehnički podaci su preuzeti sa zvaničnih sajtova proizvođača i mogu biti izmenjeni bez prethodne najave ili obaveštenja.
